Насадные резьбовые фрезы типа TMSH
Типоразмер
пластины |
Обозначение державок |
Количество
пластин |
Размеры, мм |
Комплектующие (входят в комплект) |
| IC |
D2 |
d(H7) |
H |
Винт режущей
пластины |
Ключ Torx |
Винт корпуса |
| 1/4” |
TMSH-D38-16-2 |
6 |
38,0 |
16,0 |
40,0 |
SN2T |
HK2T |
M8×1,25×35 |
| TMSH-D50-22-2 |
8 |
50,0 |
22,0 |
40,0 |
M10×1,50×35 |
| 3/8” |
TMSH-D50-22-3 |
6 |
50,0 |
22,0 |
40,0 |
SN3TM |
HK3T |
M10×1,50×35 |
| 3/8B” |
TMSH-D63-22-3B |
6 |
63,0 |
22,0 |
40,0 |
M10×1,50×35 |
| 5/8” |
TMSH-D63-22-5 |
4 |
63,0 |
22,0 |
45,0 |
SN5TM |
HK5T |
M10×1,50×35 |
| 3/4B” |
TMSH-D63-22-6B |
4 |
63,0 |
22,0 |
50,0 |
SM7T |
HK7T |
M10×1,50×35 |
| 5/8” |
TMSH-D80-27-5 |
6 |
80,0 |
27,0 |
50,0 |
SN5TM |
HK5T |
M12×1,75×40 |
| 3/4B” |
TMSH-D80-27-6B |
5 |
80,0 |
27,0 |
50,0 |
SM7T |
HK7T |
M12×1,75×40 |
| 5/8” |
TMSH-D100-32-5 |
7 |
100,0 |
32,0 |
55,0 |
SN5TM |
HK5T |
M16×2,00×40 |
| 3/4B” |
TMSH-D100-32-6B |
6 |
100,0 |
32,0 |
55,0 |
SM7T |
HK7T |
M16×2,00×40 |
| 5/8” |
TMSH-D125-40-5 |
9 |
125,0 |
40,0 |
63,0 |
SN5TM |
HK5T |
M20×2,50×50 |
| 3/4B” |
TMSH-D125-40-6B |
8 |
125,0 |
40,0 |
63,0 |
SM7T |
HK7T |
M20×2,50×50 |
|
